Technical Specifications
Single-stage adjustable delivery pressure regulator
- 0-100 psi output
- Maximum inlet pressure 3000 psi
- Durable neoprene diaphragm
- Internal reseating relief valve protects against over-pressurization
- 2โ diameter gauges
- Dual scale: psi and kPa
- DISS outlet
Stainless steel braided flexible pigtails
- PTFE inner core with SS braided outer jacket steel braid
- 24โ length
- ยผโ nominal inside diameter
- Pressure to 3000 psi
- Temperature rating -65ยฐF thru 450ยฐF
- Minimum band radius 3โ
Burst pressure 12,000 PSIG.
Inline heavy duty check valves to allow tanks to be changed without draining oxygen lines.
Inlet connections are 540 Nut and Nipple.
Not recommended for outdoor use.
