Key Features and Benefits
- Adjustable Line Regulator: Offers flexibility with adjustable line pressure settings of 0–125 psi or 0–200 psi (for Nitrogen applications), ensuring compatibility with a wide range of gas services.
- Durable Stainless Braided Pigtails: Gas-specific stainless braided pigtails are provided standard for all services except Oxygen. Optional copper pigtails are available for NFPA-compliant Oxygen service installations.
- Oxygen Service Ready: The complete system is cleaned for use with Oxygen, ensuring safety and regulatory compliance.
- Integrated Gauges: Includes a cylinder contents gauge and delivery pressure gauge for easy monitoring and control.
- Wall Mounting Bracket Included: Provides an easy and secure installation, keeping the system stable and organized.
- High Inlet Pressure Capacity: Capable of handling a maximum inlet pressure of 3,000 psi, making it suitable for a variety of applications.
- Optional Pressure Switch and Alarm: The system is available with an optional pressure switch port (1/2″ Female NPT) and a pressure switch set to 150 psi. Optional remote audio/visual alarms can also be added for enhanced safety and monitoring.
- Outlet Union Provided: The system includes a 1/2″ Male NPT outlet union for seamless connection to your gas system.
Specifications
- Gas Services Supported: Nitrous Oxide, Carbon Dioxide, Nitrogen, Medical Air, and Oxygen.
- Optional Copper Pigtails: Available for installations that require NFPA compliance for Oxygen service.
- Pressure Switch Port: Available with a 1/2″ Female NPT connection.
- Maximum Inlet Pressure: 3,000 psi, allowing for high-pressure gas applications.
